Electric bike PCB

The electric bike PCB is a key component of electric bike, which is the main basis for connecting the body electrical components and power supply. The printed circuit board provides a platform to support electrical equipment, which can stably transmit electrical energy to various parts to ensure the normal operation of the entire vehicle.

The electric bike PCB has strong bearing capacity, high withstand voltage and anti-interference capability. At the same time, it also has high resistance to line noise, ensuring stable current flux. These are important factors to ensure power supply stability.

Through the integrated design of the circuit board of electric bike, the cooperation between components can be strengthened to improve the overall power and safety performance of the vehicle. For example, the transmission system of electric bike is usually activated sequentially through the circuit board to control the starting, acceleration and deceleration of the motor and create a stable driving experience.

The electric bike board is inseparable from the basic structure of the whole vehicle. It provides a stable power supply for the whole vehicle, as well as excellent working performance and reliability. With the gradual popularization and development of electric bike, the research and development of printed circuit board will bring more new experiences to our life.

The specification of sample board

Item: electric bike board

Material:S1000-2M

Layer:8

Board thickness:2.3±0.2mm

Features:the inner copper thickness is 175um, the outer copper thickness is 105um

Main Applications

Fuji’s top priority →European market

1. Industrial (FA & Power) -- Current: 54%

2. Automotive (with safety part) -- Current: 32%
